Automatic butt welding machine with two clamping ranges per table side Path measurement and path control

The SW model range has been developed to meet the highest quality and performance requirements.

This version is equipped as standard with two clamping ranges per table side as well as travel measurement and control. Machines in this series are supplied with a CNC table force control including database and can be equipped with a fully automatic 90° welding device on customer request.

The welding cycle of this machine is fully automatic.

The machine is available in the following versions:

2 m,
3 m,
4 m,
5 m
or 6 m.

Weldable thicknesses: 3 – 30/40/50/60 mm (depending on model).

Special solutions are possible on customer request.

Additional equipment P-SW

Online diagnostic system
Illumination of the welding area
Scaling on both sides of the table
Extension to 65 mm clamping height, e.g. for hollow chamber panels
Panel lifting (one side only)
Additional clamping range per side (from 2 to 3 ranges)
T-welding program (only in conjunction with 90° L-
angle welding device)
Offset compensation, to determine and compensate for tensile and frictional forces
Automatic table gap adjustment
Remote control or foot switch for tensioning
Printer for creating a welding record in accordance with DVS 2207-11
Acoustic signal at the end of the welding cycle
Extension arms with ball casters
Automatic pressure unit
Automatic 90° L-angle welding device
Round drawing device
Special paintwork

The following models are available:

Model	Working width	Material thickness
20.30 P-SW	2,000 mm	30 mm
30.30 P-SW	3,000 mm	30 mm
40.30 P-SW	4,000 mm	30 mm
50.30 P-SW	5,000 mm	30 mm
30.40 P-SW	3,000 mm	40 mm
40.40 P-SW	4,000 mm	40 mm
50.40 P-SW	5,000 mm	40 mm
30.50 P-SW	3,000 mm	50 mm
40.50 P-SW	4,000 mm	50 mm

Precise automatic welding of plastic sheets

Automatic panel welding machines are state-of-the-art devices designed for the automated welding of panels made of various materials.

These machines offer an efficient solution for the production of large panel constructions and enable precise and reliable welding over long weld seams.

The automatic plate welding machines are equipped with a variety of functions that ensure optimum welding quality.

These include precise welding current control, automatic weld seam tracking and adjustment as well as integrated quality assurance systems.

These systems continuously monitor the welding process and enable deviations to be detected and corrected immediately.

In addition, automatic plate welding machines often have a user-friendly interface that allows the operator to easily control and monitor the welding process.

Thanks to their high productivity and precision, automatic plate welding machines are a valuable investment for companies that need to produce large plate constructions.

They offer an efficient and cost-effective solution for welding panels in various industries such as shipbuilding, the construction industry and the manufacture of special applications.
